Goulds SJ10 Vertical Deep Well Jet Pump SJ Series, 1 HP, 115/230 V, 1

Goulds SJ Vertical Deep Well Jet Pump

This well jet pump is specifically designed to deliver high capacities at deeper settings. The SJ pump is easy to service as it can be taken apart just by removing four bolts.

Includes:

• Pump
• Motor
• Pressure switch (Part# AS4)
• Tubing, fittings, pressure gauge, bushing
• Pressure control valve (Part# AV21)

Features

• Stainless steel pump shaft with hexagonal design provides positive drive for impellers and eliminates clearance adjustments
• Corrosion resistant glass filled thermoplastic impeller
• Stainless steel wear rings and coverplates
• Electrocoat paint process applied inside and out and then baked on
• Powered for continuous operation
• All ratings are within the motor manufacturer's recommended working limits
• Easy to prime - top mounted vent plug allows air to escape from seal cavity during initial priming
• Adjustable automatic pressure control valve guarantees maximum capacity at all times
• By-pass check valve equalizes pressure in entire system and helps prevent loss of prime
• Stainless steel shaft
• Built-in overload with automatic reset
• Clockwise rotation when viewed from motor end
• Pressure switch preset at 30-50 psi

Applications

• Homes
• Farms
• Cottages

Specifications:

• Brand: Goulds
• Mfg. Number: SJ10
• Series: SJ
• Product Type: Vertical jet pump
• Application: Deep well
• Horsepower: 1 HP
• Voltage: 115/230 Volts
• Phase: 1
• Stages: 2
• Frequency: 60 Hz
• Speed: 3500 rpm
• Suction Connection: 1-1/4" NPT
• Discharge Connection: 1" NPT
• Drive (Pressure) Connection: 1" NPT
• Impeller Material: Glass filled thermoplastic
• Thermal Protection: Yes
• Maximum Temperature: 140°F
• Length: 14"
• Width: 8"
• Height: 16"
